贴片MOS管

首页 » 壹芯微产品中心 » 三极管 » 贴片MOS管

型号 TYPE	PD (W)	ID (A)	V(BR)DSS (V)	RDS(ON)(max)			VGS(th)		Gfs(min)			管脚排列 PIN ARRAY
型号 TYPE	PD (W)	ID (A)	V(BR)DSS (V)	(mΩ)	ld(A)	Vgs(V)	(V)	ld(μA)	(S)	VDS(V)	lo(A)	管脚排列 PIN ARRAY
AO3400	1.4	5.8	30	28	0.7	10	0.7~1.4	250	10	5	5	GDS
AO3401	1.4	-4.2	-30	50	-4.2	-10	-0.7--1.3	-250	7	-5	-5	GDS
AO3402	1.4	4	30	52	4	10	0.5~1.5	250	14	5	3.6	GDS
AO3403	1.4	-2.6	-30	130	-2.6	-10	-0.7~-1.3	-250	3	-5	-2.5	GDS
AO3404	1.4	5.8	30	28	5.8	10	1~3	250	10	5	5.8	GDS
AO3407	1.4	-4.1	-30	52	-4.1	-5.5	-1~-3	-250	5.5	-5	-4	GDS
AO3409	1.4	-2.6	-30	130	-2.6	-10	-1~-3	-250	3	-5	-2.5	GDS
AO3413	1.4	-3	-20	97	-3	-4.5	-0.3~-1	-250	4	-5	-3	GDS
AO3414	1.4	4.2	20	50	4.2	4.5	0.4~1	250	11	5	4.2	GDS
AO3415	1	-4	-20	41	-4	-4.5	-0.3~-0.9	-250	20	-5	-4	GDS
AO6401	2	-5	-30	47	-5	-10	-0.5~-1.3	-250	18	-5	-5	GDS
AO6402	1.4	4	30	52	4	10	0.5~1.5	250	15	5	3.6	GDS
AO6404	2	8.6	20	17	8.5	10	0.5~1	250	36	5	8	GDS
AO6405	2	-5	-30	52	-5	-10	-1.4~-2.4	-250	10	-5	-5	GDS
AO6409	2.1	-5.5	-20	41	-5.5	-4.5	-0.3~-0.9	-250	20	-5	-5.5	GDS
AO6601	1.15	3.4	30	60	3.4	10	0.5~1.5	250	14	5	3.4	GDS
AO6602	1.15	3.5	30	50	3.5	10	1.5~2.5	250	12	5	3.5	GDS
AO6604	2	8.6	20	17	8.5	10	0.5~1	250	16	5	8	GDS
AO6800	1.15	3.4	30	60	3.4	10	0.5~1.5	250	14	5	3.4	GDS
AO6801	1.15	-2.3	-30	115	-2.3	-10	-0.5~-1.4	-250	8	-5	-2.3	GDS
AO6808	1.3	6	20	23	6	4.5	0.5~1	250	34	5	6	GDS
IRLML2402	0.54	1.2	20	250	0.93	4.5	0.7~	250	1.3	10	0.47	GDS
IRLML6401	1.3	-4.3	-12	50	-4.3	-4.5	-0.4~-0.95	-250	8.6	-10	-4.3	GDS
IRLML2502	1.25	4.2	20	45	4.2	4.5	0.6~1.2	250	5.8	10	4	GDS
IRLML6402	1.3	-3.7	-20	65	-3.7	-4.5	-0.4~-1.2	-250	6	-10	-3.7	GDS
2SJ210	200	-200	-60	15	-10	-4	-1.4~-2.4	-250	20	-5	-10	GDS
2SK2158	200	±0.1	50	50	1	1.5	0.5~1.1	10	20	3	10	GDS
2SK1582	200	200	30	5	10	4	0.8~1.8	250	20	5	10	GDS
2SK1590	200	0.2	60	3	10	10	0.8~1.8	250	20	5	10	GDS
BSS84	300	-130	-50	10	-0.1	-5	-0.8~-2	-250	0.05	-25	-0.1	GDS
BSS138	300	0.3	50	2.5	0.22	10	0.5~1.5	250	100	25	0.3	GDS
SI2300	1.25	3.8	20	40	5	4.5	0.6~1.5	250	5	5	5	GDS
SI2301	1.25	-2.8	-20	100	-2.8	-4.5	-0.45~-1	-250				GDS
SI2302	1.25	3	20	72	3.6	4.5	0.4~1	250				GDS
SI2303	1.25	-1.9	-30	200	-1.7	-10	-1~-3	-250				GDS
SI2304	0.25	2.5	30	65	2.5	10	1~3	250	4.6	4.5	2.5	GDS
SI2305	1.25	-4	-30	55	-4	-10	-0.4~-1.1	-250				GDS
SI2306	1.25	3.6	20	60	3.6	4.5	0.4~1	250				GDS
SI2307	1.25	-3.2	-30	78	-3.2	-10	-1~-3	250	5	-10	-3.2	GDS
SI2309	1.25	-2.2	-20	165	-2.2	-4.5	-0.5~-1.5	-250	3	-5	-2.2	GDS
AO4840	2	6	40	30	6	10	1.7~3	250	27	5	6	GDS
AO7410	0.35	1.6	30	90	1.6	10	1~1.8	250	4.5	5	3.8	GDS
AO7800	0.3	0.9	20	300	0.9	4.5	0.5~0.9	250	2.6	5	0.8	GDS
AO7801	0.3	-0.6	-20	520	-0.6	-4.5	-0.5~-0.9	250	1.7	-5	-0.6	GDS
AO8804	1.5	8	20	13	8	10	0.5~1	250	36	5	8	GDS
AO4456	3.1	20	30	4.6	20	10	1.4~2.4	250	112	5	20	GDS
AO4622	2	7.3	20	23	7.3	10	0.6~2	250	17	5	7.3	GDS
AO4442	2.5	3.1	75	130	3.1	10	1~3	250	8.2	5	3.1	GDS
AO4476	3.7	15	30	10.5	15	10	1~2.5	250	33	5	15	GDS
AO4610	2	8.5	30	18	8.5	10	1~3	250	10	5	8.5	GDS
AO4807	2	-6	-30	35	-6	-10	-1.2~-2.4	250	13	-5	-6	GDS
AO4817	2	-8	-30	18	-8	-20	-1~-3	250	15	-5	-8	GDS
AO4850	2	3.1	75	130	3.1	10	1~3	250	10	5	3.1	GDS
AO4832	1.5	8	30	15	8	10	0.6~1.4	250	23	5	8	GDS
AO4704	3.1	13	30	11.5	13	10	0.6~2	250	30	5	13	GDS
AO4454	3.1	6.5	100	36	6.5	10	2.8~4	250	20	5	6.5	GDS
AO4438	3.1	8.2	60	22	8.2	10	1~3	250	24	5	8.2	GDS
AO4615	2	7.2	30	24	7.2	10	1~3	250	10	5	4	GDS
AO4614	2	6	40	31	6	10	1~3	250	22	5	6	GDS
AO4627	2	4.5	30	50	4.5	10	1.5~2.5	250	10	5	4.5	GDS
AO4453	2.5	-9	-12	19	-9	-4.5	-0.3~-0.9	-250	-33	-5	-9	GDS
AO4600	2	6.9	30	27	6.9	10	0.7~1.4	250	12	5	5	GDS
AO4260	3.1	18	60	5.2	18	10	1.3~2.4	250	70	5	18	GDS
AO4292	3.1	8	100	23	8	10	1.6~2.7	250	30	5	8	GDS
AO4496	14	10	30	19.5	10	10	1.4~2.5	250	30	5	10	GDS
AO4604	2	6.9	30	28	6.9	5	1~3	250	10	5	6.9	GDS
AO4714	3	20	30	4.7	20	10	1.2~2.2	250	90	5	20	GDS
AO4240	3.1	24	40	3.3	20	10	1.2~2.3	250	90	5	20	GDS
AO4302	3.6	23	30	4	20	10	1.3~2.3	250	120	5	20	GDS
AO4414	3	8.5	30	26	8.5	10	1~3	250	10	5	5	GDS
AO4828	2	4.5	60	56	4.5	10	1~3	250	11	5	4.5	GDS
AO4801	2	-5	-30	49	-5	-10	-0.7~-1.3	-250	7	-5	-5	GDS
AO4421	3.1	-6.2	-60	40	-6.2	-10	-1~-3	-250	18	-5	-6.2	GDS
AO4618	2	8	40	19	8	10	1.3~2.4	250	33	5	8	GDS
AO4410	3.1	18	30	5.5	10	18	0.8~1.5	250	102	5	18	GDS
AO4411	3	-8	-30	32	-8	-10	-1.2~-2.4	-250	14.5	-5	-8	GDS
AO4459	3.1	-6.5	-30	46	-6.5	-10	-1.5~-2.5	-250	11	-5	-6.5	GDS
AO4419	3.1	-9.7	-30	20	-9.7	-10	-1.5~-2.5	-250	27	-5	-9.7	GDS
AO4607	2	6.9	30	28	6.9	10	1~3	250	10	5	6.9	GDS
AO4912	2	8.5	30	26	7	10	1~2	250	22	5	7	GDS
AO4588	3.1	20	30	4.8	20	10	1.3~2.4	250	85	5	20	GDS
AO4882	2	8	40	19	8	10	1.4~2.4	250	33	5	8	GDS
AO4310	3.6	27	36	3.1	20	10	1.2~2.3	250	151	5	20	GDS
AO4306	3.1	13	30	11.5	12	10	1.5~2.5	250	45	5	12	GDS
AO4578	3.1	20	30	5.7	20	10	1.4~2.2	250	62	5	20	GDS
AO4900	2	6.9	30	27	6.9	10	0.7~1.4	250	12	5	5	GDS
AO3401A	1.4	-4	-30	50	-4	-10	-0.5~-1.3	-250	17	-5	-4	GDS
AO3400A	1.4	5.7	30	26.5	5.7	10	0.65~1.45	250	33	5	5.7	GDS
AO3419	1.4	-3.5	-20	85	-3.5	-10	-0.5~-1.2	-250	8.6	-5	-3.5	GDS
AO3418	1.4	3.8	30	55	3.8	10	0.5~1.5	250	14	5	3.8	GDS
AO3434	1.4	4.2	30	52	4.2	10	1~1.8	250	8.5	5	4.2	GDS
AO3442	1.4	1	100	630	10	1	1.7~2.9	250	2.8	5	1	GDS
AO3416	1.4	6.5	20	22	6.5	4.5	0.4~1.1	250	50	5	6.5	GDS
AO3415A	1.5	-4	-20	41	-4	-4.5	-0.3~-0.9	-250	20	-5	-4	GDS
SI9435	2.5	-5.3	-30	50	-5.3	-10	-1~-3	-250	12	-15	-5.3	GDS
AO4803	2	-5	-30	52	-5	-10	-1~-3	-250	6	-5	-5	GDS
SI2308	1.25	5.4	20	27	5.4	4.5	0.5~1.2	250	17	10	5.4	GDS
AO4468	3.1	11.6	30	14	11.6	10	1.5~3	250	19	5	11.6	GDS
AO4606	2	6.9	30	25	6.9	10	1~3	250	10	5	6.9	GDS
AO4407	3	-12	-30	14	-10	-10	-1.7~-2.5	-250	26	-5	-10	GDS
AO4407A	3.1	-12	-30	11	-12	-20	-1.7~-3	-250	21	-5	-10	GDS
AO4411	3	-8	-30	32	-8	-10	-1.2~-2.4	-250	14.5	-5	-8	GDS
AO4435	3.1	-10	-30	18	-10	-10	-1.7~-3	-250	22	-5	-10	GDS
AO4405	3.1	-6	-30	50	-6	-10	-1.4~-2.4	-250	14	-6	-5	GDS
AO4409	3	-15	-30	7.5	-15	-10	-1.4~-2.7	-250	35	-5	-15	GDS
AO4403	3	-6.1	-30	46	-6.1	-10	-0.7~-1.3	-250	7	-5	-5	GDS
AO4406	3	11.5	30	14	12	10	0.8~1.5	250	25	5	10	GDS
AO4404	3	8.5	30	24	8.5	10	0.7~1.4	250	10	5	5	GDS
AO4408	3	12	30	14	12	10	1~2.5	250	30	5	10	GDS
AO4433	3	-11	-30	14	-11	-20	-2~-4	-250	20	-5	-11	GDS
AO4430	3	18	30	5.5	18	10	1~2.5	250	82	5	18	GDS
AO4437	3	-11	-12	16	-11	-4.5	-0.3~-1	-250	38	-5	-11	GDS
FDN335N	0.5	1.7	20	0.7	1.7	4.5	0.4~1.5	250		5	1.5	GDS
IRLML2803TRPBF	540	1.2	30	250	0.91	10	1.0~	250	0.87	10	0.46	GDS
IRLML5203TRPBF	1.25	-3.0	-30	98	-3	-10	-1~-2.5	-250	3.1	-10	-3	GDS
IRLML6302TRPBF	540	-0.78	-20	600	-0.61	-4.5	-0.7~-1.5	-250	0.56	-10	-0.31	GDS
WNM2016	0.7	2.9	20	47	3.6	4.5	0.4~1	250	8.5	5	3.1	GDS
WNM2020	0.24	0.29	20	310	0.55	4.5	0.45~0.85	250	2	5	0.55	GDS
WPM2026	0.6	-2.7	-20	65	-3.2	-4.5	-0.35~-1	-250	10	-5	-3.6	GDS
FQD1N60C	1	0.3	600	11.5	0 5.	10	2~4	250				GDS
FQD1N80	2.5	1	800	20	0.5	10	3~5	250	0.75	50	0.5	GDS
FQD2N60C	2.5	1.9	600	4.7	0.95	10	2~4	250	5	40	0.95	GDS
FQD5N60C	2.5	2.8	600	2.5	1.4	10	2~4	250	4.7	40	1.4	GDS
FQD13N06L	2.5	11	60	115	5.5	10	1~2.5	250	6	25	5.5	GDS
FQD19N10L	2.5	15.6	100	100	7.8	10	1~2	250	14	30	7.8	GDS
IRFR024NTRPBF	230	120	75	5.8	75	10	2~4	150	320	50	75	GDS
IRFR120NTRPBF	48	10	100	185	6	10	1~2	250	3.1	25	6	GDS
IRFR220NTRPBF	43	5	200	600	2.9	10	2-~4	250	2.6	50	2.9	GDS
IRFR5305TRPBF	110	-31	-55	650	-16	-10	-2~-4	-250	8	-25	-16	GDS
IRFR5410TRPBF	66	-13	-100	205	-7.8	-10	-2~-4	-250	3.2	-50	-7.8	GDS
IRFR9120NTRPBF	40	-6.6	-100	480	-3.9	-10	-2~-4	-250	1.4	-50	-4	GDS
IRFR9024NTRPBF	38	-11	-55	175	-6.6	-10	-2~-4	-250	2.5	-50	-4	GDS
IRLR024N	45	17	55	65	10	10	1~2	250	8.3	25	11	GDS
IRLR120NTRPBF	48	10	100	185	6	10	1~2	250	3.1	25	6	GDS
IRLR024NTRPBF	230	120	75	5.8	75	10	2~4	150	320	50	75	GDS
IRLR2905TRPBF	110	42	55	27	25	10	1~2	250	21	25	25	GDS
IRLR3410TRPBF	79	17	100	105	10	10	1~2	250	7.7	25	9	GDS
IRLR8726TRPBF	75	86	30	5.8	25	10	1.35~2.35	50	73	15	20	GDS
SI9410DY	2.5	7	30	30	7	10	1~3	250	15	15	7	GDS
