| 型号 | 最高反向峰值电压 | 最大平均整流电流 | 最大峰值浪涌电流 | 最大反向漏电流 | 正向压降 | 典型结电容 | 封装形式 |
| Maximum Peak Reverse Voltage | Maximum Average Rectified Current | Maximum Forward Peak Surge Current@8.3ms Single Halfsine-wave | Maximum Reverse Current | Maximum Forward Voltage | Trpe Junction Capacitance | ||
| VR(V) | IF(A) | IFSM(A) | IR(uA) | VF(V) | CJ(PF) | ||
| 直插桥式整流器 | |||||||
DB101 | 50 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB102 | 100 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB103 | 200 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB104 | 400 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB105 | 600 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB106 | 800 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB107 | 1000 | 1 | 50 | 10 | 1.1 | DB-1 | |
| DB201 | 50 | 2 | 60 | 10 | 1.1 | DB-1 | |
| DB202 | 100 | 2 | 60 | 10 | 1.1 | DB-1 | |
| DB203 | 200 | 2 | 60 | 10 | 1.1 | DB-1 | |
| DB204 | 400 | 2 | 60 | 10 | 1.1 | DB-1 | |
| DB205 | 600 | 2 | 60 | 10 | 1.1 | DB-1 | |
| DB206 | 800 | 2 | 60 | 10 | 1.1 | DB-1 | |
| DB207 | 1000 | 2 | 60 | 10 | 1.1 | DB-1 | |
| KBP2005 | 50 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP201 | 100 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP202 | 200 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP204 | 400 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP206 | 600 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP208 | 800 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP210 | 1000 | 2 | 60 | 10 | 1 | 20 | KBP |
| KBP3005 | 50 | 3 | 80 | 10 | 1 | KBP | |
| KBP301 | 100 | 3 | 80 | 10 | 1 | KBP | |
| KBP302 | 200 | 3 | 80 | 10 | 1 | KBP | |
| KBP304 | 400 | 3 | 80 | 10 | 1 | KBP | |
| KBP307 | 600 | 3 | 80 | 10 | 1 | KBP | |
| KBP308 | 800 | 3 | 80 | 10 | 1 | KBP | |
| KBP310 | 1000 | 3 | 80 | 10 | 1 | KBP | |
| KBP4005 | 50 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBP401 | 100 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBP402 | 200 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBP404 | 400 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBP406 | 600 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBP408 | 800 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBP410 | 1000 | 4 | 80 | 10 | 1.1 | 25 | KBP |
| KBPC600 | 50 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC601 | 100 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC602 | 200 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC604 | 400 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC606 | 600 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC608 | 800 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC610 | 1000 | 6 | 125 | 10 | 1.1 | 55 | KPBC |
| KBPC10005 | 50 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC1001 | 100 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC1002 | 200 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC1004 | 400 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC1006 | 600 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC1008 | 800 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC1010 | 1000 | 10 | 200 | 10 | 1.1 | KPBC | |
| KBPC15005W | 50 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC1501W | 100 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC1502W | 200 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC1504W | 400 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC1506W | 600 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC1508W | 800 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC1510W | 1000 | 15 | 300 | 10 | 1.1 | KPBC | |
| KBPC25005 | 50 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC2501 | 100 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC2502 | 200 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC2504 | 400 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC2506 | 600 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC2508 | 800 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC2510 | 1000 | 25 | 300 | 10 | 1.1 | KPBC | |
| KBPC35005 | 50 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC3501 | 100 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC3502 | 200 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC3504 | 400 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC3506 | 600 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC3508 | 800 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC3510 | 1000 | 35 | 400 | 10 | 1 | KPBC | |
| KBPC50005 | 50 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5001 | 100 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5002 | 200 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5004 | 400 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5006 | 600 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5008 | 800 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5010 | 1000 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC50005W | 50 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5001W | 100 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5002W | 200 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5004W | 400 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5006W | 600 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5008W | 800 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| KBPC5010W | 1000 | 50 | 500 | 10 | 1.2 | 300 | KPBC |
| GBP2005 | 50 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP201 | 100 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP202 | 200 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP204 | 400 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP206 | 600 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP208 | 800 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP210 | 1000 | 2 | 45 | 10 | 1.1 | GBP | |
| GBP3005 | 50 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP301 | 100 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP302 | 200 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP304 | 400 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP306 | 600 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP308 | 800 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP310 | 1000 | 3 | 90 | 10 | 1.05 | GBP | |
| GBP4005 | 50 | 4 | 110 | 10 | 1.05 | GBP | |
| GBP401 | 100 | 4 | 110 | 10 | 1.05 | GBP | |
| GBP402 | 200 | 4 | 110 | 10 | 1.05 | GBP | |
| GBP404 | 400 | 4 | 110 | 10 | 1.05 | GBP | |
| GBP406 | 600 | 4 | 110 | 10 | 1.05 | GBP | |
| GBP408 | 800 | 4 | 110 | 10 | 1.05 | GBP | |
| GBP410 | 1000 | 4 | 110 | 10 | 1.05 | GBP | |
| GBU6005 | 50 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU601 | 100 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU602 | 200 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU604 | 400 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU606 | 600 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU608 | 800 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU610 | 1000 | 6 | 175 | 10 | 1.1 | 50 | GBU |
| GBU8005 | 50 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU801 | 100 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU802 | 200 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU804 | 400 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU806 | 600 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU808 | 800 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU810 | 1000 | 8 | 170 | 5 | 1.1 | 60 | GBU |
| GBU10005 | 50 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU1001 | 100 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU1002 | 200 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU1004 | 400 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU1006 | 600 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU1008 | 800 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU1010 | 1000 | 10 | 220 | 10 | 1.1 | 70 | GBU |
| GBU25005 | 50 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| GBU2501 | 100 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| GBU2502 | 200 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| GBU2504 | 400 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| GBU2506 | 600 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| GBU2508 | 800 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| GBU2510 | 1000 | 25 | 350 | 10 | 1.1 | 70 | GBU |
| KBL400 | 50 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL401 | 100 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL402 | 200 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL404 | 400 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL406 | 600 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL408 | 800 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL410 | 1000 | 4 | 150 | 10 | 1.1 | KBL | |
| KBL6005 | 50 | 6 | 200 | 10 | 1.1 | KBL | |
| KBL601 | 100 | 6 | 200 | 10 | 1.1 | KBL | |
| KBL602 | 200 | 6 | 200 | 10 | 1.1 | KBL | |
| KBL604 | 400 | 6 | 200 | 10 | 1.1 | KBL | |
| KBL606 | 600 | 6 | 200 | 10 | 1.1 | KBL | |
| KBL608 | 800 | 6 | 200 | 10 | 1.1 | KBL | |
| KBL610 | 1000 | 6 | 200 | 10 | 1.1 | KBL | |
| KBJ4005 | 50 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ401 | 100 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ402 | 200 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ404 | 400 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ406 | 600 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ408 | 800 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ410 | 1000 | 4 | 120 | 5 | 1 | 40 | KBJ |
| KBJ6005 | 50 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ601 | 100 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ602 | 200 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ604 | 400 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ606 | 600 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ608 | 800 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ610 | 1000 | 6 | 150 | 5 | 1 | 80 | KBJ |
| KBJ10005 | 50 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ1001 | 100 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ1002 | 200 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ1004 | 400 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ1006 | 600 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ1008 | 800 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ1010 | 1000 | 10 | 170 | 5 | 1.05 | 55 | KBJ |
| KBJ15005 | 50 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBJ1501 | 100 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBJ1502 | 200 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBJ1504 | 400 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBJ1506 | 600 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBJ1508 | 800 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBJ1510 | 1000 | 15 | 200 | 10 | 1.05 | 60 | KBJ |
| KBU8005 | 50 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU801 | 100 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU802 | 200 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU804 | 400 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU806 | 600 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU808 | 800 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU810 | 1000 | 8 | 300 | 10 | 1.1 | KBU | |
| KBU10005 | 50 | 10 | 300 | 10 | 1.05 | KBU | |
| KBU1001 | 100 | 10 | 300 | 10 | 1.05 | KBU | |
| KBU1002 | 200 | 10 | 300 | 10 | 1.05 | KBU | |
| KBU1004 | 400 | 10 | 300 | 10 | 1.05 | KBU | |
| KBU1006 | 600 | 10 | 300 | 10 | 1.05 | KBU | |
| KBU1008 | 800 | 10 | 300 | 10 | 1.05 | KBU | |
| KBU1010 | 1000 | 10 | 300 | 10 | 1.05 | KBU | |
| GBPC15005 | 50 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC1501 | 100 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC1502 | 200 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC1504 | 400 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC1506 | 600 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC1508 | 800 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC1510 | 1000 | 15 | 300 | 10 | 1.1 | GBPC | |
| GBPC25005 | 50 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC2501 | 100 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC2502 | 200 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC2504 | 400 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC2506 | 600 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC2508 | 800 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC2510 | 1000 | 25 | 300 | 10 | 1.1 | GBPC | |
| GBPC35005 | 50 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC3501 | 100 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC3502 | 200 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC3504 | 400 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC3506 | 600 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC3508 | 800 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC3510 | 1000 | 35 | 400 | 10 | 1.2 | GBPC | |
| GBPC50005 | 50 | 50 | 450 | 10 | 1.1 | GBPC | |
| GBPC5001 | 100 | 50 | 450 | 10 | 1.1 | GBPC | |
| GBPC5002 | 200 | 50 | 450 | 10 | 1.1 | GBPC | |
| GBPC5004 | 400 | 50 | 450 | 10 | 1.1 | GBPC | |
| GBPC5006 | 600 | 50 | 450 | 10 | 1.1 | GBPC | |
| GBPC5008 | 800 | 50 | 450 | 10 | 1.1 | GBPC | |
| GBPC5010 | 1000 | 50 | 450 | 10 | 1.1 | GBPC | |
| W005 | 50 | 1 | 50 | 10 | 1 | WO | |
| W01 | 100 | 1 | 50 | 10 | 1 | WO | |
| W02 | 200 | 1 | 50 | 10 | 1 | WO | |
| W04 | 400 | 1 | 50 | 10 | 1 | WO | |
| W06 | 600 | 1 | 50 | 10 | 1 | WO | |
| W08 | 800 | 1 | 50 | 10 | 1 | WO | |
| W10 | 1000 | 1 | 50 | 10 | 1 | WO | |
工厂地址：安徽省六安市金寨产业园区
深圳办事处地址：深圳市福田区宝华大厦A1428
中山办事处地址：中山市古镇长安灯饰配件城C栋11卡
杭州办事处：杭州市西湖区文三西路118号杭州电子商务大厦6层B座
电话：13534146615
企业QQ：2881579535
深圳市壹芯微科技有限公司 版权所有 | 备案号：粤ICP备2020121154号
